CP-UVC-EC4K08L2C-D

CP-UVC-EC4K08L2C-D

 4K WDR HDCVI IR Fisheye Camera - 15 Mtr.

  • 1/2” 8Megapixel progressive scan CMOS (1.27cm)
  • Max. 15fps@4K
  • Panoramic fisheye lens
  • Multiple correct mode:original,panoramic,double panoramic
  • Up to 500m transmission with RG59 coaxial cable
  • WDR(120dB), Day/Night(ICR), 2D/3D-DNR, AWB, AGC, BLC, HLC
  • IR Range of 15 Mtr.
  • IP67, IK10
Datasheet User Manual
Image Sensor 1/2” 8Megapixel progressive scan CMOS (1.27cm)
Minimum Illumination 0.01Lux/F2.0 (Color), 30IRE,0lux IR on
Effective Pixels 3840(H)×2160(V), 8MP
BodyType Fisheye
Shutter Speed PAL:1/4s~1/100,000s, NTSC:1/3s~1/100,000s
White Balance Auto / Manual
Lens 2.5mm
Gain Control (AGC) Auto
S/N Ratio More than 65dB
Back Light Comp. BLC / HLC / WDR(120dB)
Video Streaming PAL: 3840×2160@12.5fps, 2560x1440@25fps; NTSC: 3840×2160@15fps, 2560x1440@30fps
Video Output 3840×2160@15fps, 2560x1440@30fps
OSD Multi-language
Resolution 8MP (3840×2160)/4MP(2560x1440)
ICR Auto (Electronic) / Manual
Audio Built- in Mic
Alarm IN 2 channel
Alarm Out 1 channel
IR IR Range of 15 Mtr.
Operating Temperature -30°C~+60°C/ Less than 90%RH
Power Source DC12V ±25%
Power Consumption 7.4W (IR ON)
Dimension Φ150mm x 50.7mm
Weight 0.56 kg
